Equip your heavy-duty air disc brake system with this premium Type 18/24 Disc Brake Chamber by FleetPro Parts & Tires. Specifically engineered for modern commercial air disc brakes, this chamber delivers the precise actuation and rapid release required for safe, reliable stopping power. Manufactured to meet or exceed strict SAE specifications, this unit ensures your fleet remains DOT compliant and on the road. We stock these heavily right here in our Hanover Park, Illinois warehouse to guarantee lightning-fast shipping for owner-operators and fleets across the Midwest and nationwide.
Professional-Grade Stopping Power: The Type 18/24 Disc Brake Chamber Advantage
This Type 18/24 Disc Brake Chamber is built to outlast standard aftermarket replacements in the harshest road conditions. It features a precise 2.25" standard short stroke and a 15mm ram, ensuring exact pad-to-rotor contact every time you hit the pedal. Note: This unit is built with metric M16-1.5 mounting studs (spaced at the industry-standard 4.75") and 90-degree 3/8" NPTF air ports to perfectly match your factory air disc setup.
As we continue to build the largest inventory of commercial truck parts in Illinois, we prioritize safety-critical brake components that you can trust. Backed by FleetPro's rigorous quality control, this chamber serves as a direct universal replacement for hundreds of major industry part numbers, including Bendix K132352, K043314, and Haldex GC1824D. Upgrade your air disc brakes today with a reliable, leak-free FleetPro chamber.
Vehicle Fitment & Compatibility
This spring brake chamber is designed strictly for heavy-duty commercial air disc brake applications:
-
Application: Heavy-Duty Tractor & Trailer Air Disc Brakes
-
Chamber Type: Type 18/24 (Spring Combination)
Direct Replacement & Cross-Reference Numbers:
This chamber directly replaces dozens of OEM and aftermarket numbers, including but not limited to:
-
Bendix: K132352, K043314, K026127, 5017127, 802477, BW5017127, BXK132352
-
Haldex: GC1824D
-
Automann: 179.SB1824DB, AM179SB1824DB
-
Navistar / Fleetcraft: 1824ADSB, 1824TLD2
-
MGM Brakes: 3419-TR1724LTH
-
Industry Standards: 1824-D, 1824CBD, T18/24
Technical Specifications
-
Stroke Type: Standard Short Stroke (2.25")
-
Chamber Type: Type 18/24
-
Ram Size: 15 mm
-
Mounting Stud Spacing: 4.75" (Center to Center)
-
Mounting Stud Threads: M16 - 1.5
-
Mounting Stud Length: 1.72"
-
Air Port Thread Size: 3/8" - 18 NPTF
-
Air Port Position: 90 Degrees
-
Overall Length: 9.125"
Cross references: Bendix K132352 • Bendix K043329 • Bendix K026451 • Bendix K025670 • Haldex GC1824D • Automann 179.SB1824DB • MGM 3419-TR1724LTH • TSE 1824TLD2 • FleetRun FR-BRKE874
